Features

• 6.5" PulseTouch Display
• 280,800 pixels
• 1 A/V Output and 1 A/V Input
• Rear Camera Input
• 3 PreOuts
• 50W x 4 High Power Amp
• DVD-Audio as 2-Ch Down-Mix Only
• TV Tuner Compatibility: TUE-T200DVB, T112P
• Processor Control Ready
• Full Speed Connection for iPod® (Required KCE-422i)

Specifications

Dimensions

• Din Size:2
• Chassis Size (W x H x D) mm: 178mm x 100mm x 165mm

General

• Power Requirement 14.4 V DC
  (11–16 V allowable)
• Operating temperature +32°F to +113°F
  (0°C to + 45°C)
• Maximum Power Output 50 W × 4
• Output Voltage 2,000 mV/10k ohms
• Bass ±14 dB at 60 Hz
• Treble ±14 dB at 10 kHz
• Weight 2.9 kg (6 lbs. 22 oz)
